博物志 - 一份设计说明书

Last updated on

:本文主要由 AI(Claude)协助撰写整理,属于 DeepSearch 系列。内容基于实际代码库分析和设计决策记录。

这是一份设计说明书。博客完全通过 vibe-coding 搭建——没有前端经验,靠着直觉、Claude 的帮助和不断试错,一点点把想法变成现实。

本文采用 Apple Human Interface Guidelines (HIG) 的分类方式组织,从基础到具体:Foundations → Patterns → Components


Overview

设计哲学

HIG 核心原则:Clarity(清晰)、Consistency(一致)、Deference(克制)

博客对这三个原则的本地化诠释:

HIG 原则博客体现
Clarity内容优先,UI 元素用途一目了然,无装饰性复杂度
Consistency统一的 token 系统,相同组件在不同页面使用相同样式
Deference克制的 hover 效果,动效保持最小化,UI 不干扰阅读

博客 DNA

  • 暖色调:拒绝冷色,浅色暖白、深色夜棕
  • 极简交互:hover 只调颜色/边框,不位移
  • 内容为王:排版和组件都服务于阅读体验

技术栈概述

使用 Astro 静态优先架构 + Tailwind CSS 4 样式系统,部署在 Cloudflare Pages。详细配置见代码库。


Foundations

Color

HIG: Color can provide visual continuity, communicate status information, give feedback in response to user actions, and help people visualize data.

设计决策

拒绝冷色调——大多数博客在深色模式转向冷蓝/冷灰,但这里始终保持温暖:

  • 浅色模式:暖白底 #fffaf4(像旧书页)
  • 深色模式:暗夜棕 #140e0b(像老木桌)

单一强调色:琥珀橘 #fb8f68

所有需要强调的元素(粗体、链接 hover、标签、按钮)都用这个颜色,形成统一的视觉节奏。

Token 层级

用途浅色深色
页面背景#fffaf4#140e0b
卡片背景#ffffff#1c1512
主要文字#2a1c17#f5ebe0
次要文字#46342a#c4b5a8
弱化文字#7b6454#8c7d6f
强调色#fb8f68#fb9f74

博客变体:配色起点来自 Obsidian Shiba Inu 主题,经调整形成”旧书页+琥珀”风格。

Tailwind 集成

色彩 token 通过 @theme inline 映射到 Tailwind utilities:

@theme inline {
  --color-bg-page: var(--color-bg-page);
  --color-accent: var(--color-accent);
  /* ... */
}

使用时直接写 bg-bg-pagetext-accent 等 utility class。


Typography

HIG: Typography helps establish hierarchy and express your app’s character. Use fonts that are easy to read and complement the content.

字号系统

基础字号 17px,符合 Apple HIG 推荐的移动端阅读标准:

用途字号
正文17px (1.0625rem)
小字15px (0.9375rem)
标题 h130px (1.875rem)
标题 h224px (1.5rem)
标题 h320px (1.25rem)

行高与字距

  • 标题line-height: 1.22(紧凑,强调视觉重量)
  • 正文line-height: 1.75(宽松,适合长时间阅读)
  • 中文字距letter-spacing: 0.01em(略微增加字间距)

字体选择

博客变体:使用 jf-openhuninn-2.0(粉圓體)而非系统字体,增加温暖手写感。

粗体特殊处理:所有 <strong> 自动应用强调色,而非仅加粗。


Spacing & Layout

HIG: Adequate spacing helps people focus on key information and understand the relationship between onscreen elements.

设计原语

原语用途
.page-shell页面容器,最大宽度 max-w-5xl (1024px),响应式内边距
.section-stack纵向节奏,使用 clamp() 实现响应式间距
.measure正文行长 68ch,符合可读性推荐(60-80 字符)

关键尺寸

Token说明
--space-41rem基础间距单位
--space-82remSection 上下距离
--radius-lg16px大圆角(卡片、图片)
--radius-md12px中圆角(紧凑组件)

Dark Mode

HIG: Dark Mode uses a dark color palette that works system-wide and provides a comfortable viewing experience in low-light environments.

切换策略

三态循环:system → light → dark → system

  • 主题状态保存在 localStorage
  • 页面加载时提前注入,避免 FOUC(Flash of Unstyled Content)
  • 通过 [data-theme="dark"] 选择器切换所有 token

深色模式适配

  • 所有色彩 token 都有对应的深色版本
  • 阴影在深色模式下更加柔和
  • 保持暖色调基底(夜棕而非冷黑)

Patterns

HIG: Navigation should feel natural and unobtrusive, helping people experience and interact with your content without drawing attention to itself.

桌面端

横排导航栏,固定在顶部。导航项使用统一的 hover 样式。

移动端

抽屉式导航:

  • 点击按钮打开,ESC 或点击遮罩关闭
  • 打开时锁定 body 滚动
  • 焦点管理:关闭后焦点回到触发按钮

Content Architecture

HIG: Give people a clear path through your experience by organizing information and flows logically.

内容类型

类型集合特点
长文blog深度文章,完整叙事
月记monthly生活状态,阶段总结
TILtilToday I Learned,快速记录

三者共享统一的 frontmatter schema、排版样式(.prose)和标签索引系统。

架构图

首页

文章索引 /blog

文章页 /[slug]

目录

灯箱

评论

动态 /channel

帖子卡片

链接预览

回复引用

漫画表情包 /mangashots

标签索引 /tags

动态内容

Telegram 频道 (/channel):

  • SSR 渲染,5 分钟缓存
  • 双栏布局:帖子流 + 频道信息侧边栏
  • 支持链接预览、回复引用、Hashtag 标签

漫画表情包 (/mangashots):

  • 无限滚动,Cloudflare D1 存储

Modals & Overlays

HIG: Use modality only when clarity or focus is essential. When you use modality, keep experiences brief and focused.

统一组件

站点所有模态场景使用同一套实现模式:

  • 灯箱Lightbox.astro):图片预览
  • 抽屉:导航菜单、目录

行为规范

行为实现
打开显示 <dialog> 元素,锁定滚动
关闭ESC 键、点击遮罩、关闭按钮
焦点打开时移入,关闭时回到触发元素

滚动锁定

统一使用 .scroll-locked 类:

body.scroll-locked {
  overflow: hidden;
}

Components

Cards

HIG: A card displays a set of related information in a compact format, providing easy access to the actions and details the card presents.

变体

变体用途
.surface-card默认卡片,带边框和阴影
.surface-card--soft弱边框 + 混合背景,无阴影
.surface-card--flat无阴影,仅保留边框
.surface-card--compact使用较小圆角

Hover 策略

博客变体:不使用 translateY 上浮效果,保持视觉克制。

  • .surface-card--hover-border:hover 时边框颜色加深
  • .surface-card--hover-none:禁用 hover 效果

Pills & Tags

HIG: A tag is a keyword or label that helps identify and organize items.

.pill 组件用于文章标签、过滤器等场景:

  • 背景使用强调色的淡化版本
  • Hover 时背景加深、边框显现
  • 不使用位移动效

Code Blocks

HIG: Present code in a way that helps people understand its structure and purpose.

功能

  • 语言标识(右上角)
  • 复制按钮
  • 双主题配色(Shiki 高亮)

配色

模式背景
浅色#f6f8fa
深色#282a36

Images

HIG: Images communicate information quickly and can make a strong emotional connection with people.

正文图片

  • 圆角:16px
  • 阴影:var(--shadow-soft)
  • 点击打开灯箱

灯箱功能

Lightbox.astro 组件提供:

  • 左右导航(键盘 ← →、触摸滑动)
  • 图片计数(1 / 5)
  • Alt/Caption 文本展示
  • 支持动态内容(事件委托模式)
  • 边界事件(可触发加载更多)

Accessibility

HIG: Accessibility is a core element of a great experience that helps everyone get the most from their devices.

对比度

所有文字配色满足 WCAG AA 标准(4.5:1+):

文字类型对比度
主要文字12.5:1+
次要文字7.2:1+
弱化文字4.5:1+

键盘导航

  • ESC:关闭所有对话框/抽屉
  • ← →:灯箱切换图片
  • Tab:循环焦点(Trap focus)
  • 清晰的 focus-visible 样式

动效降级

检测 prefers-reduced-motion 偏好:

@media (prefers-reduced-motion: reduce) {
  html {
    scroll-behavior: auto;
  }
  *,
  *::before,
  *::after {
    animation-duration: 0.01ms !important;
    transition-duration: 0.01ms !important;
  }
}

缓存与性能

资源策略
静态文章长缓存
动态频道5 分钟 + stale-while-revalidate
图片代理一年缓存

使用 rehype-img-size 自动写入图片宽高,防止 CLS(Cumulative Layout Shift)。
